Main Filter |
HEPA Filter (99.97% efficient at 0.3 micron particles) |
|
|
Prefilter |
High-efficiency nylon filter |
|
|
Air Velocity |
0.3~0.5 m/sec (9-phase controllable) |
|
|
Illumination |
Fluorescent Lamp 40W or 20W |
|
|
Sterilizing |
UV Lamp 40W xor 20W |
|
|
Controller |
LCD Microprocessor (Filter Change Alarm) |
|
|
Materials |
Internal Material |
Stainless Steel Plate |
|
Exterior Material |
Steel Plate with Powder Coating |
|
|
Window |
High Temperature safety glass of thickness 5mm |
|
|
Door |
Sliding Glass Door/Tempered Safety Glass |
|
|
Utility |
Air Cock, Gas Cock, Electric Outlets (AC 220V x 1ea) |
|
|
Supply Voltage & Frequency |
AC 220V, 50/60Hz |
|
|
MODEL |
LST-1100-V/ LST-1100-B |
LST-1300-V/ LST-1300-B |
LST-1600-V/ LST-1600-B |
|
External Dimension (L x D x H) (mm) |
1000 x 800 x 1995 / 2000 |
1,300 x 800 x 1,955 / 2000 |
1.600 x 800 x 1,955 / 2000 |
|
Internal Dimension (L x D x H) (mm) |
1,100 x 580 x 680 |
1,200 x 580 x 680 |
1,500 x 580 x 680 |
|
Type |
Vertical Type/ Bio Type |
Vertical Type/ Boi Type |
Vertical Type/ Boi Type |
