Model |
VB-7 |
|
|
Capacity |
7 Liter |
|
|
Internal Dimension (W x D x H) (mm) |
310 x 155 x 150 (140 x 155 x 150) |
|
|
External Dimension (W x D x H) (mm) |
350 x 495 x 420 |
|
|
Heater Capacity |
1.5 KW |
|
|
Net weight (kg) |
24kg |
|
|
Temp |
Range |
-10°C~90°C |
|
Controller |
LCD Program PID Controller (1 Pattern 10 Segment) |
|
|
Sensor |
PT-100Ω |
|
|
Timer |
Range |
99Hr 59Min |
|
Controller |
LCD Digital Display |
|
|
Material |
Internal Material |
Stainless Steel |
|
External Material |
Steel Plate with Powder Coating |
|
|
Heater |
Stainless Steel |
|
|
Insulation |
poly urethane Foam |
|
|
Pump Capacity |
6 Liter/Min |
|
|
Refrigerator |
Air Cooling Unit System |
|
|
Safety |
Over Temp Protector |
|
|
Power |
AC 220V, 60Hz, 1Ø |
|
